2-3-3. FUNCTIONS
It is used to select the function screen displayed in the editing area shown in Figure 2-6. The contents of
the function are as follows.
Controls the parison wall profile and other related functions (When start up the control-
ler, first move to this screen)
Set program point marker.
Slope setting for die gap and start slope.
Time setting of internal clock.
PURGE / TOOLING target position setting
Allows storage and retrieval of 100 container wall thickness programs and related func-
tions
Display status of digital signal and current value of servo valve current and die gap
position. Manual operation is also done on this screen.
Displays the profile point and related function data
Set Up Mode – Provides die gap tooling and other machine related set up functions
Analog monitor assignment to monitor channels.
Delete and Backup/Restore the storage data. (Backup/Restore for data in USB)
Machine primary setting setup
Communication parameter setting RS422 and Ethernet. And Inter clock time setting
2-3-4. STATE MONITORING AREA
In the status monitoring area shown in Figure 2-6, it is used to indicate the state of the function as shown
below.
Lights when the cycle Start signal is received
Lights when the Die Gap signal is received and “DIE GAP” on the LCD is
back lit
Lit when the “Continuous Extrusion” machine type is selected
Lit when “Accumulator” machine type is selected
Lit when “Divergent” die gap tooling is selected
Lit when “Convergent” die gap tooling is selected
Lights when the accumulator completes its charging stroke
Lights when each Marker point is reached
Lights when the accumulator completes its empty stroke
