2-6. PROFILE DATA LIST
Prpfile Data address and data
form
address
name
range
screen
content
1
File no
1～100
F3
"0" is F1 screen profile data
2
File name
F1,F2,F3,F5
max 32 characters
3
Date
F3
yy/mm/dd hh:mm:ss 17 characters
4
00
Shot size/Cycle
time
1 ～ 9999
F1
Shot size[0.1%]/Cycle time[0.1sec]
5
01
Die gap
0 ～ 1000
F1
[0.1%]
6
02
Delay
0 ～ 9999
F1
[0.1%]
7
03
Cushion
0 ～ 9999
F1
[0.1%]
8
04
Die gap slope
1 ～ 9999
F2
[0.1%/sec]
9
05
Start slope
1 ～ 9999
F2
[0.1%/sec]
10
06
Spline
0=invalid
SHIFT→F4
1=valid
11
07
Core stroke
1 ～ 9999
SHIFT→F1
unit 0.01mm Tooling length
12
08
Accum. stroke
1 ～ 9999
SHIFT→F1
unit 0.1mm
13
09
DCDT zero
-1000 ～ 1000
SHIFT→F1
set voltage : unit [0.01V]
14
0A
DCDT span
-1000 ～ 1000
SHIFT→F1
set voltage : unit [0.01V]
15
0B
Accum. Empty
0 ～ 1000
SHIFT→F1
set voltage : unit [0.01V]
16
0C
Accum. Full
0 ～ 1000
SHIFT→F1
set voltage : unit [0.01V]
17
0D
Type set
bit0: 0 = Divergent, 1=
Convergent
SHIFT→F1
（Core type)
bit1: 0 = %, 1 = mm
（Core stroke unit）
bit2: 0 = %, 1 = mm
(Accumulator stroke unit）
bit3: 0 = Extrusion fixed, 1 =
Filling fixed
（Accumulator type only）
bit4: 0 = OFF, 1 = ON
（Auto cycle）
18
0E
Gain
1～32767
SHIFT→F1
[0.01]
19
70
Marker point 1
0～200
F2
Profile point 1～200 （"0" is not out-
put）
20
71
Marker point 2
0～200
F2
21
72
Marker point 3
0～200
F2
22
73
Marker point 4
0～200
F2
23
74
Marker point 5
0～200
F2
24
75
Marker point 6
0～200
F2
25
76
Marker point 7
0～200
F2
26
77
Marker point 8
0～200
F2
27
78
Marker point 9
0～200
F2
28
79
Marker point 10
0～200
F2
29
80
Profile point 1
-1 ～ 1000
F1
[0.1%]
30
81
Profile point 2
-1 ～ 1000
F1
[0.1%]
～
～
～
～
～
～
228
147
Profile point 200
-1 ～ 1000
F1
[0.1%]
229
148
PURGE gap
0～1000
[F2]
[0.1%]
230
149
TOOLING gap
0～1000
[F2]
[0.1%]
