2.3
Attaching the Antenna
Prerequisites: Ensure the radio is turned off before attaching the antenna.
Procedure:
1 Set the antenna in the receptacle.
2 Turn the antenna clockwise to attach to the radio.
3 To remove the antenna, turn the antenna counterclockwise.
NOTE: When removing the antenna, ensure that the radio is turned off.
2.4
Removing and Attaching the Accessory Connector Cover
The accessory connector is on the antenna side of the radio. It is used to connect accessories to the
radio.
NOTE: To prevent damage to the connector, shield it with the connector cover when not in use.
Procedure:
1 To remove the accessory connector cover, rotate the thumbscrew counterclockwise until it
disengages from the radio.
NOTE: If the thumbscrew is too tight, use an allen wrench to loosen it.
2 Rotate and lift the connector cover to disengage it from the radio.
3 To attach the accessory connector cover, insert the hooked end of the cover into the slot above
the connector.
4 Press the top of the cover downward to seat it in the slot.
5 Tighten by rotating the thumbscrew clockwise by hand.
2.5
Using the Carry Holder
Procedure:
1 Position the radio within the carry holder with the main speaker facing outward.
2 Slide the radio down into the carry holder until it clicks in place.
3 To remove the radio from the carry holder, place the tip of your fingers on the ledge of the carry
holder.
4 Push at the bottom of the radio until the radio is released from it.
2.6
Turning On the Radio
Procedure:
1 Rotate the On/Off/Volume Control Knob clockwise until you hear a click.
MN001425A01-AW
Chapter 2 : Getting Started
19
