Page #29 background imageLoading...
Page #29 background image
The red LED blinks continuously.
NOTE:
The radio alerts you when NNTN8921and NNTN8930 batteries are attached to the radio
because these batteries are not supported. The radio is not HAZLOC-certified and resets if
these batteries are used. Refer to the radio FM or UL Manual for more information.
The radio does not display any indication when the radio is connected to the charger, the radio
and battery match, or when the radio certification type is configured as None in Customer
Programming Software (CPS).
This feature is enabled through CPS configuration. Check with your dealer or system administrator for
more information.
4.2
LED Indications
The LED indications represent the operational status of your radio. A qualified technician can
permanently disable the LED indication by programming it.
Table 2: LED Indications
Indication Status
Solid red Radio is transmitting.
Blinking red Radio is transmitting at low battery condition.
Double blinking red Radio is transmitting an emergency alarm or call.
Rapid blinking red Radio has failed the self-test upon powering up or encountered a fatal
error.
Solid yellow Radio is receiving in both trunking and conventional clear mode.
NOTE: The yellow LED illuminates only when the Busy LED
feature is enabled through Customer Programming Software
(CPS).
Blinking yellow Radio is receiving a secured transmission.
Solid green Radio is powering up or is on a non-priority channel while in the Scan List
Programming mode.
Blinking green Radio is receiving an individual or telephone call or is on a Priority-Two
channel while in the Scan List Programming mode.
Rapid blinking green Radio is on a Priority-One channel while in the Scan List Programming
mode.
4.3
Status Icons
The LCD display of your radio shows radio status, text entries, and menu entries. The top two display
rows contain color icons that indicate radio operating conditions.
Selected icons are also shown on the first row of the 112 x 32 pixel top monochrome display screen of
your radio.
The following icons are for the front display screen unless indicated otherwise.
MN001425A01-AW
Chapter 4 : Status Indicators
29
