Motorola TETRA User Manual

45
DMO Group Call
• “None”, indicating that no gateway
was selected for that talkgroup. Enter
an address via the keypad, and press
Ok. The Gateway icon will blink upon
selecting the gateway.
When the MTM800 detects the suitable
gateway, the Gateway icon will turn solid.
Selecting DMO Group Call via Repeater
While in DMO, proceed as follows to choose the Repeater
option to set up a call via Repeater for the selected talkgroup:
1. Press Optns, use the navigation keys to scroll to
3 Config.
and press Ok.
2. Scroll to
3 Repeater and press Ok.
3. The MTM800 will use the first available
repeater for that talkgroup. The repeater
icon will blink upon selecting that option.
When the MTM800 detects the proper
repeater presence signal, the Repeater
icon will turn solid.
Selecting DMO Group Call via Gateway and Repeater
While in DMO, proceed as follows to choose the Gateway
and Repeater option to set up a call via Gateway or Repeater
(Gateway preferred) for the selected talkgroup.
1. Press Optns, scroll to 3 Config. and press Ok.
2. Scroll to 4 GW + Rep and press Ok.
3. The display shows the last “GW + Rep.”
type selection. Use the navigation key to
scroll to your selection and press Ok:
Automatic — the MTM800 will use the
first available gateway for that talkgroup. The Gateway icon
and the repeater icon will blink upon selecting that option.
None
Selected GW:
Ok
Back
DMO Range1
DMO TG1
DMO TG10
DMO Range1
DMO Range1
DMO TG10
1 Automatic
2 Specific
Ok
Back
6815321H01_KOR.book Page 45 Thursday, November 13, 2008 8:06 AM

Motorola TETRA Specifications

General

Operating Temperature	-30°C to +60°C
Storage Temperature	-40°C to +85°C
Receiver Static Sensitivity	-116 dBm
Dust and Water Protection	IP54
IP Rating	IP54
Display	Monochrome or color LCD (depending on model)
Frequency Bands	380-400 MHz, 410-430 MHz, 450-470 MHz
Weight	300g
