MTS Systems FlexTest GT User Manual

MTS 793 Controller Hardware
Installing the 493.02 Chassis (FlexTest SE)
Installation
56
Installing the Handle Kit
The Controller may be equipped with an optional handle kit.
The following procedure provides assembly and installation
instructions for the handle kit (MTS PN 100-061-494). The following
table and figure show the handle kit assembly components described
in the procedure.
Handle Kit Parts
I
TEM DESCRIPTION QUANTITY
1 Support arm 2
2 Handle side leg 2
3 Clip 2
4 Washer 4
5 Screw 2
6 Spring 2
7 Button 2
8 Ratchet 2
9 Ratchet housing 2
10 Lock washer 2
11 Handle screw 2
12 Handle 1
13 Cover 2
