MTS 793 Controller Hardware
Installing 497/498 Electronics (FTIIm)
Installation
62
Analog Chassis Plug-in Modules
Before you install any plug-in modules, be sure they are configured
properly for your system. The following is a brief description of the
plug-in modules available for the chassis.
Plug-in Modules
M
ODEL #PLUG-IN MODULE NAME FUNCTION
497.13
*
* This conditioner is normalized and can be swapped (with a conditioner of the same model number)
without recalibrating the sensor/conditioner pair. Normalized conditioners contain an EEPROM in
which normalization values are stored during manufacturing. These values compensate for
variations in conditioner components.
AC Conditioner
Processes signals from AC-type sensors such as LVDTs or
RVDTs.
Note This module was designed to replace the 497.14 AC
Conditioner.
497.15 Three-Stage Valve Driver
Produces the control signal and inner control loop for a
256 or a 257 Servovalve.
497.22
*
Dual DC Conditioner
Processes the signals from two DC-type sensors such as a
force transducer or extensometer.
497.26 Two-Stage Valve Driver
Produces the control signal for one 252 Servovalve. The
second valve driver is not used in standard systems.
497.34 Multistation Interlock
Controller
Monitors the plug-in modules for interlocks. This is a part
of the interlock chain between 497.05 chassis and any
other 497.01 chassis.
497.36 Communication Module
Provides communications between the 497.01 Analog
Chassis and the 498.22 Test Processor.
