MTS 793 Controller Hardware FlexTest GT Controller Connections
75
• Disconnect the overall shield from the metallized back shell at the
external device and add a capacitor (approximately 0.01 μf) to
one end of the cable between the shield and the metallized
backshell.
• Disconnect the overall shield from the metallized back shell at the
external device.
Typical Cabling
For additional cables, see “Cable Part Numbers” on page 76.
Actuator
Manifold
(HSM)
RearFront
MTS Sysrtems Corp
14000 Technologyu Dr.
Eden Prairie, MN 555344-2290 USA
Assy No:
Model: S/N
l
Power
OK
Over
Temp
J39 Power Monitor
Power
l
LVDT
Force Sensor
Servovalve
Load Unit Control
Workstation
HPU
Remote
Station
Control
052-544-2xx
052-543-1xx
052-544-2xx
052-542-5xx
056-126-4xx
039-708-3xx
051-996-8xx
055-634-2xx (E-stop)
or 055-634-3xx (Station Stop
056-126-5xx
039-713-7xx
Connectors with
Transducer ID modules
Hold
Stop
Run
Off
Low
High
HPS
Off
Low
Interlock HSM Test Manual Control
F1 F2 F3 F4 Status
Remote Station Control
Enable /
Disable
Reset High
Emergency Stop
r
Hydrau
li
c
Power Unit Con
trol
r
Typical cabling of a
FlexTest system
