MTS 793 Controller Hardware FlexTest GT Controller Connections
81
Temposonics III The connection requires a DC conditioning mezzanine card.
TO
493.40 CARRIER MODULE
(TEMPOSONICS III
DAUGHTER BOARD)
Data
Clock
+
+
-
-
+24 V
COM
TO
493.74
AUX POWER
Data
Clock
+24 V
COM
+
-
+
-
FROM
TEMPOSONICS III
SENSOR
