MTS 793 Controller Hardware
FlexTest GT Controller Connections
92
Sensor cables with ID
Module
See the System Cable/Jumper Plug 493 Package Selection drawing (PN
700-000-656) for the most sensor cable current part numbers.
Each sensor includes a cable with an ID module built into it. Use a
system cable to bridge the sensor cable to the rear panel of the
controller chassis.
Shunt Calibration/Bridge Completion Resistor Installation
On a typical system, shunt calibration and bridge completion resistor
installation is completed on the I/O Carrier module.
If you have purchased optional sensor cables with transducer ID
modules, shunt calibration and bridge resistors are installed on these
modules.
Sensor Cables and Connectors (ID Module)
C
ABLE DESCRIPTION ID MODULE W/CABLE
SYSTEM CABLE
*
* -XX specifies cable length. –01 through –09 represent 10–50 ft. in 5 ft. increments. Higher
numbers represent custom cable lengths
.
M
ODULE
C
ONNECTOR
ADT 120º
300º
052-543-5XX
052-443-6XX
056-125-8XX
056-125-9XX
493.40 J4–J7
493.40 J4–J7
Extensometer 633 capacitive 052-543-4XX 052-544-3XX 493.40 J4–J7
Force Transducer w/PT connector
w/PC connector
w/MS connector
052-542-5XX
052-542-6XX
052-542-7XX
052-544-2XX
052-544-2XX
052-544-2XX
493.40 J4–J7
493.40 J4–J7
493.40 J4–J7
LV D T 052-543-1XX 052-544-2XX 493.40 J4–J7
ΔP control
052-543-2XX 052-544-2XX 493.40 J4–J7
Pressure Control (Sensotec) 052-543-3XX 052-544-2XX 493.40 J4–J7
Strain w/Amphenol connector
w/PT connector
052-542-9XX
052-543-0XX
052-544-2XX
052-544-2XX
493.40 J4–J7
493.40 J4–J7
Te m p o s o n i c s
Temposonics II (low power conditioner)
052-543-7XX
052-543-8XX
056-126-0XX
052-544-7XX
493.40 J4–J7
493.40 J4–J7
RVDT w/MS connector 052-750-8XX 052-544-2XX 493.40 J4–J7
