Configure a G-240W-G indoor ONT
102
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
4 Click Save.
5 STOP. This procedure is complete.
Procedure 21 Wireless scheduling
1 Select Network > Wireless Schedule from the top-level menu in the GPON Gateway window,
as shown in Figure 37.
Figure 37 Wireless Schedule window
2 Select the Schedule Function checkbox to turn the wireless signal off for the configured
period.
3 Click the plus sign (+) to add a scheduling rule.
A separate panel displays for configuring wireless schedule rules.
4 Enter a start time and end time for the period in which you want the wireless signal off.
5 Choose Everyday or Individual Days from the drop-down menu.
Release 05.08.01a | August 2018 | Edition 01
