7368 ISAM ONT G-240W-G Product Guide Configure a G-240W-G indoor ONT
Issue: 01 3FE-47555-AAAA-TCZZA 131
Procedure 37 DDNS configuration
1 Select Application > DDNS from the top-level menu in the GPON Home Gateway window, as
shown in Figure 56.
Figure 56 DDNS window
Table 47 describes the fields in the DDNS window.
Table 47 DDNS parameters
2 Configure DDNS.
Field Description
WAN Connection List Choose a WAN connection from the drop-down menu
Enable DDNS Select this checkbox to enable DDNS on the chosen WAN connection
ISP Choose an ISP from the drop-down menu.
Domain Name Domain name
Username Username
Password Password
DDNS Status Displays the status of the DDNS: Synchronized, Synchronization failed,
or blank if no update message has been received from the ISP.
Release 05.08.01a | August 2018 | Edition 01
