7368 ISAM ONT G-240W-G Product Guide Configure a G-240W-G indoor ONT
Issue: 01 3FE-47555-AAAA-TCZZA 125
Procedure 33 DMZ and ALG configuration
1 Select Security > DMZ and ALG from the top-level menu in the GPON Home Gateway
window, as shown in Figure 52.
Figure 52 DMZ and ALG window
Table 43 describes the fields in the DMZ and ALG window.
Table 43 DMZ and ALG parameters
2 Configure ALG.
3 Click Save ALG.
4 Configure DMZ.
Field Description
ALG Config Select the checkboxes to enable the protocols to be supported by the ALG: FTP,
TFTP, SIP, H323, RTSP, L2TP, IPSEC, PPTP
DMZ Config
WAN Connection List Choose a WAN connection from the drop-down menu
Enable DMZ Select this checkbox to enable DMZ on the chosen WAN connection
DMZ IP Address Choose Customer Setting and enter the DMZ IP address or choose the IP address
of a connected device from the drop-down menu
Release 05.08.01a | August 2018 | Edition 01
