Configure a G-240W-G indoor ONT
128
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Procedure 35 Port forwarding configuration
1 Select Application > Port forwarding from the top-level menu in the GPON Home Gateway
window, as shown in Figure 54.
Figure 54 Port forwarding window
Table 45 describes the fields in the port forwarding window.
Table 45 Port forwarding parameters
2 Configure port forwarding.
Field Description
Application Name Choose an application name from the drop-down menu
WAN Port WAN port range
LAN Port LAN port range
Internal Client Choose a connected device from the drop-down menu and enter the associated IP
address
Protocol Choose the port forwarding protocol from the drop-down menu:
• TCP
• UDP
• TCP/UDP
Enable Mapping Select this checkbox to enable mapping
WAN Connection List Choose a WAN connection from the drop-down menu
Note: only active devices are shown on this menu
Release 05.08.01a | August 2018 | Edition 01
