7368 ISAM ONT G-240W-G Product Guide Configure a G-240W-G indoor ONT
Issue: 01 3FE-47555-AAAA-TCZZA 119
Procedure 30 IP filter configuration
1 Select Security > IP filter from the top-level menu in the GPON Home Gateway window, as
shown in Figure 49.
Figure 49 IP filter window
Table 40 describes the fields in the IP filter window. If the firewall level is not set to advanced,
the IP filter rules are not available.
Table 40 IP filter parameters
Field Description
Mode Choose an IP filter mode from the drop-down menu:
• Drop for upstream
• Drop for downstream
Internal Client Choose an internal client from the drop-down menu:
• Customer setting - uses the IP address input below
• IP - uses the connecting devices' IP to the ONT
Local IP Address Local IP address
Source Subnet Mask Source subnet mask
Remote IP Address Remote IP address
Destination Subnet Mask Destination subnet mask
Protocol Choose an application protocol or all from the drop-down menu
Release 05.08.01a | August 2018 | Edition 01
