7368 ISAM ONT G-240W-G Product Guide Configure a G-240W-G indoor ONT
Issue: 01 3FE-47555-AAAA-TCZZA 75
Procedure 8 LAN status retrieval
1 Select Status > LAN Status from the top-level menu in the GPON Home Gateway window,
as shown in Figure 20.
Figure 20 LAN status window
Table 18 describes the fields in the LAN status window.
Table 18 LAN status parameters
Field Description
Wireless Information
Wireless Status Indicates whether the wireless is on or off
Wireless Channel Wireless channel number
SSID Name Name of each SSID
Wireless Encryption Status Encryption type used on the wireless connection
Wireless Rx Packets Number of packets received on the wireless connection
Wireless Tx Packets Number of packets transmitted on the wireless connection
Wireless Rx Bytes Number of bytes received on the wireless connection
Wireless Tx Bytes Number of bytes transmitted on the wireless connection
(1 of 2)
Release 05.08.01a | August 2018 | Edition 01
