Configure a G-240W-G indoor ONT
114
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
7 Configure the US classifier.
At least one field must be selected to create a classifier. A maximum of four fields may be
selected to create a classifier; this includes the interface field.
8 Click Save.
9 To delete a classifier, click the Delete option for the applicable classifier in the classifier table.
A classifier can only be deleted if it is not associated with any classifier rules.
10 Select the Classifier Rules tab, as shown in Figure 46.
All classifier rules are displayed in the classifier rules table in the window.
Figure 46 US Classifier Rules window
Destination IP Click to enter a destination IP
Source Port Click to enter a source port
Destination Port Click to enter a destination port
Protocol Click to enter a protocol
Priority Choose a priority level from 1 to 8. The lower the number, the higher the
priority. No more than 1 classifier can be created with the same priority.
Field Description
(2 of 2)
Release 05.08.01a | August 2018 | Edition 01
