Configure a G-240W-G indoor ONT
110
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Figure 43 QoS Config window (L3)
Table 34 describes the fields in the QoS Config window.
Table 34 QoS Config parameters
Field Description
Type Choose a QoS service layer type from the drop-down menu L2 or L3.
Source MAC Enter the source MAC
Select the Exclude checkbox to exclude the source MAC
Interface Choose an interface from the drop-down menu
DSCP Mark Enter the value for the DSCP mark (range: 0-63); valid only for L3 Criteria
802.1p Mark Enter the value for the 802.1p (range: 0-7)
(1 of 2)
Release 05.08.01a | August 2018 | Edition 01
