7368 ISAM ONT G-240W-G Product Guide Configure a G-240W-G indoor ONT
Issue: 01 3FE-47555-AAAA-TCZZA 105
Procedure 23 DNS configuration
1 Select Network > DNS from the top-level menu in the GPON Home Gateway window, as
shown in Figure 39.
Figure 39 DNS network window
Table 31 describes the fields in the DNS network window.
Table 31 DNS network parameters
2 Select the Enabled checkbox and click Save to enable the DNS proxy.
3 Enter the domain name and IPv4 address and click Add.
Field Description
DNS Proxy Select the Enabled checkbox to enable the DNS
proxy
Domain Name Domain name
IPv4 Address Domain IP address
Origin Domain Origin domain name
New Domain New domain name
Release 05.08.01a | August 2018 | Edition 01
