Configure a G-240W-G indoor ONT
96
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Procedure 18 WAN DHCP configuration
1 Select Network > WAN DHCP from the top-level menu in the GPON Home Gateway window,
as shown in Figure 34.
Figure 34 WAN DHCP window
Table 27 describes the fields in the WAN DHCP window.
Table 27 WAN DHCP parameters
2 Configure a WAN DHCP option.
Field Description
WAN Connection List Choose a WAN connection from the drop-down menu
DHCP Option 50
Persistent
Select this checkbox to enable DHCP Option 50 persistent
Enable DHCP Option 60 Select this checkbox to enable DHCP Option 60 (vendor class identifier)
Enable DHCP Option 61 Select this checkbox to enable DHCP Option 61 (client identifier)
Enable DHCP Option 77 Select this checkbox to enable DHCP Option 77
Enable DHCP Option 90 Select this checkbox to enable DHCP Option 90
Release 05.08.01a | August 2018 | Edition 01
