7368 ISAM ONT G-240W-G Product Guide Configure a G-240W-G indoor ONT
Issue: 01 3FE-47555-AAAA-TCZZA 81
2 Click Delete to delete a particular local device connection.
3 Click Refresh to update the displayed information.
4 STOP. This procedure is complete.
Procedure 12 Optics module status retrieval
1 Select Status > Optics Module Status from the top-level menu in the GPON Home Gateway
window, as shown in Figure 24.
Figure 24 Optics module status window
Table 22 describes the fields in the Optics module status window.
Access Point Hexadecimal address of the wireless access point
Local Devices
Table entry Each entry indicates the status (active or inactive), connection type, device name, IP
address, hardware address, and IP address allocation of each connected local device.
Field Description
(2 of 2)
Release 05.08.01a | August 2018 | Edition 01
