Configure a G-240W-G indoor ONT
90
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Procedure 15 LAN networking configuration
1 Select Network > LAN from the top-level menu in the GPON Home Gateway window, as
shown in Figure 31.
Figure 31 LAN network window
Table 24 describes the fields in the LAN network window.
Table 24 LAN network parameters
Field Description
Port Mode
All Ports to Bridge Mode Select this checkbox to set all ports to Bridge mode
Port 1 - 4 Drop-down port mode for each port: Route mode or Bridge mode
IPv4 Address IP Address of the ONT
Subnet Mask Subnet mask of the ONT
DHCP Enable Select this checkbox to enable DHCP
DHCP Start IP Address Starting DHCP IP address
(1 of 2)
Release 05.08.01a | August 2018 | Edition 01
