Configure a G-240W-G indoor ONT
148
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Procedure 51 Diagnose WAN connections
1 Select Maintenance > Diagnose from the top-level menu in the GPON Home Gateway
window, as shown in Figure 70.
Figure 70 Diagnose window
2 Choose a WAN connection to diagnose from the drop-down menu.
3 Enter the IP address or domain name.
4 Select the test type: ping, traceroute, or both.
5 Enter the number of ping attempts to perform (1 - 1000); the default is 4.
6 Enter a ping packet length (64-1024); the default is 64.
7 Enter the maximum number of trace hops (1-255); the default is 30.
8 Click Start Test. Results will be displayed at the bottom of the window.
Release 05.08.01a | August 2018 | Edition 01
