Configure a G-240W-G indoor ONT
80
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Procedure 11 Home networking information retrieval
1 Select Status > Home Networking from the top-level menu in the GPON Home Gateway
window, as shown in Figure 23.
Figure 23 Home networking information window
Table 21 describes the fields in the Home networking window.
Table 21 Home networking parameters
Field Description
Local Interface
Ethernet Table displays the number of Ethernet connections and their settings
Wireless (2.4GHz) Table displays the number of wireless connections and their settings
Wireless (5GHz)
Wireless Settings (2.4GHz)
Network Name Name of the wireless network
Access Point Hexadecimal address of the wireless access point
Wireless Settings (5GHz)
Network Name Name of the wireless network
(1 of 2)
Release 05.08.01a | August 2018 | Edition 01
