Configure a Beacon G6
Network configuration
Configuring QoS
Table 7-18 QoS config parameters
Select a QoS service layer type from the list:
• L2 Criteria
• L3 Criteria
Classification criteria (L2)
Enter the source MAC address.
Select the toggle button to exclude the source MAC address.
Select an interface from the list.
Classification criteria (L3)
Select a protocol from the list.
Select the toggle button to exclude the protocol.
Select an application from the list or select Custom Settings and enter an application name.
Enter the source IP address.
Select the toggle button to exclude the source IP address.
Enter the source IP address netmask.
Enter the destination IP address.
Select the toggle button to exclude the destination IP address.
Enter the destination IP address netmask.
Enter the source port number.
Select the toggle button to exclude the source port.
Enter the values for the source port max (highest port number)
Enter the destination port number.
Select the toggle button to exclude the destination port.
Enter the values for the destination port max (highest port number)
Enter the value for the DSCP remark (applicable only for L3 criteria).
Allowed values: 0 to 63
Enter the value for the 802.1p remark.
Allowed values: 0 to 7
Enter the number for the forwarding policy.
Allowed values: 1 to 7
