Install or replace a Beacon G6
Replace a Beacon G6
4
Connect the WAN cable to the RJ-45 WAN port; see Figure 6-1, “Beacon G6 connections”
(p. 55)for the location of the RJ-45 WAN port.
5
Connect the power cable to the power connector.
Note: Units must be powered by a Listed or CE approved and marked limited power
source power supply with a minimum output rate of 12 V dc, 2 A. The polarity of the power
adapter plug must match the Beacon G6.
6
Power up the unit by using the On/Off power switch. The POWER LED indicator should be solid
green in color.
7
Verify the LEDs and voltage status. The Table 5-6, “Beacon G6 indoor LED descriptions”
(p. 46) indicates the behavior of the LEDs.
8
Activate and test the services.
9
If the Beacon G6 is in a failure state or is not providing the services that are expected, perform
a factory reset.
Note: Resetting the device will return all settings to factory default values; any customized
configuration will be lost.
a. Locate the Reset button as shown in Figure 6-1, “Beacon G6 connections” (p. 55).
b. Insert the end of a straightened paper clip or other narrow object into the hole and keep the
reset button pushed for 10s until the Power LED blinks red.
c. Your device will reboot with the factory default settings.
END OF STEPS
6.6 Replace a Beacon G6
1
Power down the unit by using the on/off power switch. See for the connections on the Beacon
G6.
Use subject to agreed restrictions on disclosure and use.
56 3FE-49949-AAAA-TCZZA
