Beacon G6 unit data sheet
Beacon G6 detailed specifications
Table 5-6 Beacon G6 indoor LED descriptions
Light failed on startup (for example corrupt flash), or self test failed on startup, or self test
failed during regular operation.
No WAN ethernet cable connected. No physical uplink.
WAN has a physical uplink and is synced at 2.5Gbps or 1Gbps
WAN has a physical uplink and is synced at 100 or 10M
HSI WAN is connected the device has an IP address assigned from IPCP, DHCP, or
static.
PPPoE or DHCP connection is in progress.
HSI WAN is not connected, the reasons could be either of the following:
• there is no physical interface connection
• the device is in bridge mode without an assigned IP address
• the session has been dropped for reasons other than idle time-out.
WiFi protected setup link is up (negotiation and auto-configuration successful)
WiFi protected setup link activity (negotiation and auto-configuration ongoing)
WiFi protected setup processing exception or multiple peers using WPS simultaneously
WiFi protected setup link down or no link connected (negotiation has not started or has
failed)
WiFi enabled for at least one radio frequency (RF)
WiFi data traffic passing
WAN/LAN/ RJ45
(Executed on the
RJ45 connectors)
LAN link is OFF or has LOS (line of signal) transmission issue.
5.7 Beacon G6 detailed specifications
The following table lists the physical specifications for Beacon G6 .
Table 5-7 Beacon G6 indoor physical specifications
Height (including antenna)
Use subject to agreed restrictions on disclosure and use.
46 3FE-49949-AAAA-TCZZA
