Network Interface Board (NIB-96)
$SSOLFDWLRQV
AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 5-7
1,%6/&DQG(,$&RQQHFWLRQV
Figure 5-6 shows the pinouts for SLC (P5) and EIA-485 (P4) connections on the
NIB-96 board. The EIA-485 circuit requires a serial connection. Connect only one wire
to each screw terminal.
)LJXUH 6/& DQG (,$ &RQQHFWLRQV
:LULQJ6SHFLILFDWLRQV
Table 5-5 contains the wiring specifications for wiring an SLC and an EIA-485 circuit:
7DEOH 1,% :LULQJ 6SHFLILFDWLRQV
Circuit Wiring Specifications
SLC Loop Supervised and power-limited
Maximum wiring distance: 10,000 feet at 12 AWG
Maximum loop current: 200 mA (short circuit) or 100 mA (normal)
Maximum loop resistance: 40 ohms
EIA-485 Supervised and power-limited
±5 volts peak-to-peak
Maximum wiring distance: 6000 feet at 14 AWG
Maximum circuit resistance: 40 ohms
Characteristic impedance of wiring: 120 ohms
Transmission rate: 2400 baud
3
² 6/&
3
² (,$
(,$ /RRS 2XW
(,$ /RRS ,Q
² (,$ /RRS 2XW
² (,$ /RRS ,Q
1R FRQQHFWLRQ
1R FRQQHFWLRQ
6/& /RRS ,Q
6/& /RRS ,Q 6 KLHOG
6/& /RRS ,Q ²
(DUWK JURXQG
6/& /RRS 2 XW
6/& /RRS 2 XW 6KLHOG
6/& /RRS 2 XW ²
(DUWK JURXQG
