5. MAINTENANCE MENUS
5.4.2 Normal self-diagnostic mode (level 1)
The following is the normal self-diagnostic mode menu:
Option
Self-diagnostic menu
item
Adjustment
Maintenance
Utility
1 Switch scan test SWITCH SCAN Performs input sensor and
switch checking.
No. 21
2 Motor and clutch
test
MOTOR&CLTCH
TEST
Tests motor and clutch
operation.
No. 22
3 Test printing TEST PRINT Prints a test pattern stored in
the PU.
Unavailable
4 Color registration
adjustmenttest
REG ADJUST
TEST
Judges the color registration
adjustmentmechanismas
pass or fail.
No. 23
5 Densityadjustment
test
DENS ADJ TEST Judgesthedensityadjustment
mechanism as pass or fail.
No. 24
6 Consumable
counter display
CONSUMABLE
STATU S
Displays consumable usage. No. 26
7 Consumable life
counter display
PRINTER STATUS Displays consumable life. No. 26
8 Factory/Shipping
mode setting
FACTORY MODE
SET
Switches between the Factory
and Shipping modes
No. 3,
No. 27
9 Fuse status display Displays the status of the
fuses.
No. 27
10 Engine parameter
setting
SENSOR SETTING Sets whether to enable
or disable error detection
performed by each sensor.
No.28
11 NVRAM parameter
setting
NVRAM
PARAMETER
Must not be used. Unavailable
5.4.2.1 Entering self-diagnostic mode (level 1)
1. Make sure that the LCD is in standby state (no Error window is shown) and
press the [Setting] to move to the setting widow and then press the following
button in the indicated sequence.
[#]
→
[0]
→
[1]
→
[0]
→
[3]
→
[
]
2. Type in the password to enter Service Maintenance Menu. It is [000000] by
default. (Enter 0 six times)
3. Select [Printer Maintenance]
→
[Engine Diag Mode] in the Service Maintenance
Menu and press the [6].
5.4.2.2 Exiting self-diagnostic mode
1. When the [4] is pressed from Diag Mode (Window displaying/Factory state), the
setting window will return.
