Oki MC562w Maintenance Manual

44952001TH Rev.2
5-29
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
5.4.11 Self-diagnostic function setup
The self-diagnostic function setup is used for enabling or disabling the error detection by
sensors. The detection can be enabled or disabled temporarily for troubleshooting. Allowing
for setting engine operation options for which expert knowledge is required to be handled,
these self-diagnostic setup should be used carefully.
Be sure to restore the default settings of used options of the self-diagnostic function setup.
1. Enter the self-diagnostic mode and, until the following message appears, press [2]
or [8].
SENSOR SETTING
2. Press [2] or [8], and the following message appears. Press [2] or [8] until an
option to set (refer to the table shown below) appears.
TONER SENSOR
ENABLE *
3. A setting can be selected on the lower display by pressing the [6] button. [2]
displays the next setting and [8] displays the preceding setting.
4. Press the [6] button with the display showing the setting to set. The setting is
stored in the EEPROM. The state for step 2 is restored.
5. Repeat steps 2 through 4 when necessary.
6. Press [4] to end setting the option (except where not in step 4) (the state for step
1 is restored).
Display Settings Behavior Function
TONER
SENSOR
ENABLE Performs detection. Enables or disables the toner
sensor operation.
DISABLE Does not perform
detection.
BELT UNIT
CHECK
ENABLE
Performs checking. Enables or disables the belt
installation checking operation.
DISABLE
Does not perform
checking.
Display Settings Behavior Function
ID UNIT
CHECK
ENABLE
Performs checking. Enables or disables the image drum
installation checking operation.
DISABLE
Does not perform
checking.
UP/DOWN
SENSOR
ENABLE
Performs detection. Enables or disables the image drum
up-down sensor operation.
DISABLE
Does not perform
detection.
REG ADJUST
ERROR
ENABLE
Has the printer to
pause.
Enables or disables the error display
based on a color misregistration
detection value.
DISABLE
Does not have the
printer to pause.
DRUM OVER
LIFE
STOP
Does not extend
life.
Sets whether to enable or disable
extending image drum life at the
end of the life.
CONTINUANCE
Extends life.
WR POINT
REV
TBL=**H±
*.***mm
00H FFH
A correction value. Adds a correction value for the
default writing point.
BOTTOM
WRT POINT
TBL=**H±
*.***mm
00H FFH
A tear-off value. Sets a tear-off length from the
bottom edge of paper.
Default is in hatched area
