44952001TH Re
v
.2
1-30
Oki Data CONFIDENTIAL
1.
CONFIGURA
TION
1.5.5
Wireless LAN Interf
ace (MC342w/MC352w)
1.5.5.1 Outline of
Wireless LAN
(
1
) Specification
IEEE802
.
1
1
b
/
g
/
n(
2.4GHz)
(2
)
Power co
nnec
tor
USB M
icr
o B
(3
)
Power sup
ply volt
age
5V
(4)
MFP si
de inter
fac
es
IEEE 802
.3u 10
/1
0
0
BASE (L
AN po
r
t)
USB Micro B
Chip Antena
LAN Port
X: Do not connect.
(Blue)
(Yellow)
Note!
This
product cannot c
onnect to a
wired LAN and wireles
s LAN at the
same time.
