44952001TH Rev.2

5-20

Oki Data CONFIDENTIAL

5. MAINTENANCE MENUS

Tabl e 5 - 4

Unit name displayed Driving restriction Remarks

ID MOTOR All of the (black, yellow, magenta and cyan)

image drums must be removed.

–

BELT MOTOR All of the (black, yellow, magenta and cyan)

image drums must be removed.

–

FUSER_MOTOR – –

REGIST MOTOR – –

T1 HOPPING MOTOR – –

FRONT MOTOR – –

REGIST SHUTTER – –

DUPLEX MOTOR – –

DUPLEX CLUTCH – –

T2 HOPPING MOTOR – Option

T2 FEED CLUTCH – Option

ID UP/DOWN The top and front cover must be closed. –

LV FAN TEST – –

ID FAN TEST – –

FRONT FAN TEST – –

Note: Display while ID UP/DOWN is in progress

MOTOR & CLUTCH TEST

ID UP/DOWN ***

***

: Identiﬁes the number of executions

Display after pressing REGIST SHUTTER [

] button

MOTOR & CLUTCH TEST

SHT ***

***

: Identiﬁes the number of executions
