27
Wiring Section 3-2
Pulse Outputs Pulse Outputs Using CW/CCW Outputs
Pulse Outputs Using Pulse + Direction Outputs
PWM(891) Outputs
Note PWM(891) output 1 can be used only with the CJ1M-CPU22/CPU23.
General-purpose output 5 OUT5 36 Output 5
37 Power supply input
(+V) for the output
39 or 40 Output COM
Output number Code Pin No. Content
Output number Code Pin No. Content
Pulse output 0 OUT0 31 CW pulse output
32 CCW pulse output
37 Power supply input
(+V) for the output
39 or 40 Output COM
Pulse output 1 OUT1 33 CW pulse output
34 CCW pulse output
37 Power supply input
(+V) for the output
39 or 40 Output COM
Output number Code Pin No. Content
Pulse output 0 OUT0 31 Pulse output
33 Direction output
37 Power supply input
(+V) for the output
39 or 40 Output COM
Pulse output 1 OUT1 32 Pulse output
34 Direction output
37 Power supply input
(+V) for the output
39 or 40 Output COM
Output number Code Pin No. Content
PWM(891) output 0 OUT4 35 PWM(891) output
39 or 40 Output COM
PWM(891) output 1
(See note.)
OUT5 36 PWM(891) output
39 or 40 Output COM
