PLC Setup Settings Section 4-2
Pulse Output 1 Settings
Note CX-Programmer Tabs
CX-Programmer Ver. 3.1 or lower: Define Origin Operation Settings Field of
Define Origin 2
CX-Programmer Ver. 3.2 or higher: Pulse Output 1
Speed (Target Speed for Pulse Output 1 Origin Return)
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Acceleration Rate (Pulse Output 1 Origin Return Acceleration Rate)
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Deceleration (Pulse Output 1 Origin Return Deceleration Rate)
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
288 00 to 15 00000001 to
000186A0 hex
(See note.)
00000000
hex
Specifies the target speed (1 to
100,000 pps) for pulse output 1 origin
return operation.
--- When operation
starts
289 00 to 15
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
290 00 to 15 Pre-Ver. 2.0 CPU
Units: 0001 to
07D0 hex
CPU Units Ver.
2.0: 0001 to FFFF
hex
(See note.)
0000
hex
Sets the origin search acceleration
rate for pulse output 0.
Pre-Ver. 2.0 CPU Units:
1 to 2,000 pulses/4 ms
CPU Units Ver. 2.0:
1 to 65,535 pulses/4 ms
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
291 00 to 15 Pre-Ver. 2.0 CPU
Units: 0001 to
07D0 hex
CPU Units Ver.
2.0: 0001 to FFFF
hex
(See note.)
0000
hex
Sets the origin search deceleration
rate for pulse output 0.
Pre-Ver. 2.0 CPU Units:
1 to 2,000 pulses/4 ms
CPU Units Ver. 2.0:
1 to 65,535 pulses/4 ms
--- When operation
starts
