64
PLC Setup Settings Section 4-2
Pulse Output 1 Origin Proximity Input Signal Type
Pulse Output 1 Limit Input Signal Type
Pulse Output 1 Origin Search/Return Initial Speed
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Pulse Output 1 Origin Search High Speed
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Pulse Output 1 Origin Search Proximity Speed
Note When the CX-Programmer is being used to make the setting, the setting is
input in decimal.
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
286 04 to 07 0 hex: NC
1 hex: NO
0 hex Specifies whether the Origin Proxim-
ity Input Signal for pulse output 1 is
normally closed or normally open.
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
286 00 to 03 0 hex: NC
1 hex: NO
0 hex Specifies whether the limit input sig-
nal for pulse output 1 is normally
closed or normally open.
--- When operation
starts
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
276 00 to 15 00000000 to
000186A0 hex
(See note.)
00000000
hex
Specifies the starting speed (0 to
100,000 pps) for the pulse output 1
origin search and origin return opera-
tions.
--- When operation
starts
277 00 to 15
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
278 00 to 15 00000001 to
000186A0 hex
(See note.)
00000001
hex
Specifies the high speed setting (1 to
100,000 pps) for pulse output 1 origin
search operation.
--- When operation
starts
279 00 to 15
Programming
Console setting
address
Settings Default Function Related
Auxiliary
Area flags/
bits
Time when
setting is read
by CPU Unit
Word Bits
280 00 to 15 00000001 to
000186A0 hex
(See note.)
00000000
hex
Specifies the proximity speed setting
(1 to 100,000 pps) for pulse output 1
origin search operation.
--- When operation
starts
281 00 to 15
