8 Other Useful Functions
8 - 8
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
8-5 Changing the System Environment
You can change the system data for the FH vision sensor in the system data editing screen.
Display the system data editing screen in the Edit Pane by double-clicking [System] in the Multiview
Explorer or by right-clicking it and selecting [Edit] from the menu.
System data is classified into the groups shown in Table 1.
Clicking a group icon displays the editing items for the corresponding group.
System data includes parameters that require a restart to reflect the settings.
If a parameter that requires a restart is edited, " " is displayed for the sensor type in the Multiview
Explorer. If " " is displayed, save the settings and then restart the FH vision sensor.
For details on restarting, refer to 2-4-4 Multiview Explorer on page 2-10.
For details on each setting item, refer to Vision System FH/FZ5 Series User's Manual (Cat. No. Z365).
To Next Page
