1 Overview
1 - 4
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
Eight FH vision sensor series devices can be registered to one project.
In the FH sensor controller series, the following types of data provided by Sysmac Studio are managed
as project data.
• Scene group data (scene data)
• System data
• Tool data (communications command macros, security settings, and other data)
By using the Multi-line Random-trigger Mode, the FH sensor controller independently processes multi-
ple processing lines at the same time.
Project data manages this data together as one batch. These data can also be exported and imported
individually as file data.
1-2-1 Project data
FH sensor
Line
Project data
Line
Line
Scene group data
Scene group data
Command
customize
data
System
data
Tool data
Scene data
Scene group data
Scene data
Scene data
