2 Basic Operations
2 - 10
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
• This pane will be the access point for all data of the FH series.
• You can right-click any data item that can be set and select an item from the menu (context menu).
You can also display various editing screens in the Edit Pane.
• Multiview Explorer can be displayed or hidden by clicking the display/hide bar on the left side of the
window. Even when hidden, it can be displayed temporarily by placing the mouse pointer over the
display/hide bar. Moving the mouse pointer away from the bar returns the Multiview Explorer to the
hidden state.
2-4-2 Menu Bar
Menu Name Description
File
Close Closes the project.
Save Saves the project.
Save As Saves the project with a different name.
Save As New Number Saves the project with a new update number.
Import Imports an exported file so that it can be edited in the tool.
Export Saves the project as an external file.
Exit Closes Sysmac Studio.
Edit
Copy Copies the selected item.
Paste Pastes the copied item.
Delete Deletes the selected item.
View
Multiview Explorer Displays the Multiview Explorer.
Toolbox Displays the Toolbox.
Reset Window Layout Resets the window layout.
Insert
Controller Inserts an NJ or NX project.
Displacement Sensor Inserts a ZW project.
Vision Sensor Inserts an FQ-M or FH project.
Tools Options Displays the Options menu.
Help
Help Contents
Displays “Vision System FH Series Operation Manual Sysmac Stu-
dio (Cat. No. Z343)."
Online Registration Performs online registration.
Keyboard Mapping Reference Displays the shortcut key reference.
About Sysmac Studio Displays the version of Sysmac Studio.
2-4-3 Toolbar
Button Name Description
Copy Copies the selected item.
Paste Pastes the copied item.
Delete Deletes the selected item.
Help
Displays Vision System FH Series Operation Manual Sysmac Studio
(Cat. No. Z343)
2-4-4 Multiview Explorer
To Next Page
