Omron fh series Operation Manual

2 - 3
2 Basic Operations
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
2-1 Basic Design Flow 1
2
2-1 Basic Design Flow 1
This section describes the flow for designing a system that uses NJ/NX-series CPU Unit as a controller.
For details on the program on the NJ/NX-series CPU Unit side, task design, and debugging, refer to
Sysmac Studio Version 1 Operation Manual (Cat. No. W504-E1-08 or later).
z
New project settings
Create a project file.
1 Starting Sysmac Studio
Start Sysmac Studio.
Refer to 3-3-1 Starting and Exiting the Sysmac Studio in Sysmac Studio Version 1 Operation
Manual (Cat. No. W504-E1-08 or later).
2 Designing a new project
Create a new project.
Refer to 3-3-2 Creating a Project File in Sysmac Studio Version 1 Operation Manual (Cat. No.
W504-E1-08 or later).
z
Controller configuration and settings
• Controller configuration
(1) Creating an EtherCAT configuration
Register FH as an EtherCAT slave in [EtherCAT].
Refer to 5-1 EtherCAT Configuration and Settings in Sysmac Studio Version 1 Operation
Manual (Cat. No. W504-E1-08 or later).
(2) Registering device variables
When using or using after editing device variables for the user defined variables to connect
the FH I/O information and program, register the device variables in [I/O Map].
Refer to 4-1-2 Creating Device Variables in Sysmac Studio Version 1 Operation Manual
(Cat. No. W504-E1-08 or later).
• Controller settings
(1) Editing slave parameters
Edit the Operation Settings of the slaves.
Refer to 5-2-1 Creating the EtherCAT Slave Terminal Configuration in Sysmac Studio Ver-
sion 1 Operation Manual (Cat. No. W504-E1-08 or later).
z
Sensor connection
Establish an online connection with the sensor.
(1) Connecting a sensor
Refer to Section 3 Connecting with a Vision Sensor
