Appendices
A - 2
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
A-1 Sysmac Device Features
The control device product designed according to standardized communications and user interface
specifications for OMRON control devices are called a Sysmac Device.
And the features available with such a Device is called Sysmac Device Features.
Because, in Sysmac Devices, errors that may occur in slaves are systematized, you can check the
causes and remedies for errors with a common procedure.
The status of an error can be monitored in the Sysmac Error Status (2002-01 hex). To display the error
status detected by the FH series Vision Sensor in Sysmac Studio, the Sysmac Error Status (2002-01
hex) must be mapped to the PDO. Sysmac Studio, by default, uses the 512th transmit PDO Mapping
assignment to map the Sysmac Error Status (2002-01 hex) automatically to the PDO.
Additional Information
• For the Sysmac Error status (2002-01 hex), refer to Vision System FH/FZ5 Series User's
Manual for Communications Settings (Cat. No. Z342).
• For errors displayed in Sysmac Studio, refer to NJ/NX-series Troubleshooting Manual (Cat.
No. W503).
A-1-1 Sysmac Error Status
