3 - 3
3 Connecting with a Vision Sensor
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
3-1 Adding FH Series Vision Sensor on the Network to a
Project
3
3-1 Adding FH Series Vision Sensor on
the Network to a Project
When creating a new project or adding FH vision sensor to a project, select FH vision sensor on the
network.
When connecting to the FH vision sensor, right-click [Device Group] in the Multiview Explorer and then
select [Add | FH].
The following sensor selection screen appears.
When establishing an online connection, click [Search for sensors] and then click the [Search] button.
The found sensors are displayed in a list. Select the sensor you wish to connect to and then click the
[OK] button.
If you know the IP address of the sensor you wish to connect to beforehand or will connect to a sensor
via a router, select the [Specify the IP address.] check box and then enter the IP address in [IP
address]. After input is complete, click the [OK] button.
Precautions for Correct Use
If there is already a different FH slave device in the project with an established online connec-
tion, you will not be able to select the [Search for sensors] option.
To Next Page
