8 - 21
8 Other Useful Functions
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
8-15 Using the Conveyor Panorama Display tool
8
8-15 Using the Conveyor Panorama Dis-
play tool
This tool is used for conveyor tracking applications.
To adjust the trigger interval and conveyor speed for additional lines or new product types, this tool
combines images to create a panoramic image, and then displays the region of captured image and the
registered region of the model of the target objects for the pick operation over it.
For more details, refer to Vision Sensor FH Series Conveyor Tracking Application Programming Guide.
