Omron fh series Operation Manual

4 - 11
4 Configuring Measurement Settings
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
4-2 Editing a Processing Unit
4
4-2-6 Detection Point/Reference Point
The detection point and reference point can be set with the numerical value input boxes.
Clicking any place in the displayed image reflects that coordinate value as the setting value.
Selecting an item in the list displays the information for the selected item below the list. Each of the
information items displayed below the list can be edited.
This allows you to select the image to display. Refer to File selection section on page 2-18.
4-2-6 Detection Point/Reference Point
4-2-7 List
4-2-8 Image Control Area
File selection section
