8 - 13
8 Other Useful Functions
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
8-9 Using the Image File Save Tool
8
8-9-1 Opening the Image File Save Tool
8-9 Using the Image File Save Tool
With this tool, it is possible to save the copy of both logged images and image files that are saved in the
Image Sensor to a RAM disk or external memory device in FH Vision Sensor, or to a computer.
The save image file format can be selected from “Bitmap” or “Jpeg”.
Double-click on [Tool] - [Image file save] in the Multiview Explorer, or by right-clicking it and selecting
[Edit] from the menu.
The image file save tool window is displayed in the Edit Pane.
8-9-1 Opening the Image File Save Tool
