Touch Panel Monitor of FH-MT12 is connectable FH-1000, FH-3000, and FH-L Sensor Controller
whose software is Ver.5.32 or later.
For connection of Touch Panel Monitor and FH Sensor Controller, the monitor cable for video and touch
panel cable are necessary.
Precautions for Safe Use
About connection of FH-1000, FH-3000, FH-L series Sensor Controller and FH-MT12.
Do not ground the plus (+) terminal of the 24VDC power source when the Sensor Controller is
connected to the FH-MT12 with a USB cable.
Doing so may cause a short circuit of the internal circuit, resulting in a malfunction.
Touch Panel Monitor
Specification
Model FH-MT12
Major Function Display area 12.1 inch
Resolution 1024 (V) × 768 (H)
Number of color 16,700,000 colors (8 bit/color)
Brightness
500 cd/m
2
(Typ)
Contrast Ratio 600:1 (Typ)
Viewing angle Left and right: each 80°, upward: 80°, downward: 60°
Backlight Unit LED, edge-light
Backlight lifetime About 100,000 hour
Touch panel 4wire resistive touch screen
External inter-
face
Video input analog RGB
Touch panel signal USB
RS-232C
Ratings Power supply voltage 24 VDC±10%
Current consumption 0.5 A
Insulation resistance Between DC power supply and Touch Panel Monitor FG: 20
MΩ or higher (rated voltage 250 V)
Operating
environment
Ambient temperature range Operating: 0 to 50°C,
Storage: -20 to +65°C (with no icing or condensation)
Ambient humidity range Operating and Storage: 20 to 85%RH
(with no icing or condensation)
Ambient environment No corrosive gas
Vibration resistance 10 to 150 Hz, one-side amplitude 0.1 mm
(Max. acceleration 15 m/s
2
)
10 times for 8 minutes for each three direction
Degree of protection Panel mounting: IP65 on the front
Operation Touch pen
Structure Mounting Panel mounting, VESA mounting
Weight Approx. 2.6 kg
Material Front panel: PC/PBT, Front Sheet: PET, Rear case: SUS
