Vision System FH/FZ5 series Hardware Setup Manual (Z366)

Precautions for Correct Use

Install and store the product in a location that meets the following conditions:

• Surrounding temperature of 0 to +50°C

• No rapid changes in temperature (place where dew does not form)

• Relative humidity of between 35 to 85%RH

• No presence of corrosive or flammable gases

• Place free of dust, salts and iron particles

• Place free of vibration and shock

• Place out of direct sunlight

• Place where it will not come into contact with water, oils or chemicals

Install and store the product in a location that meets the following conditions:

• Surrounding temperature of the following environment:

• Installation: 0 to 55°C in

• Storage: -25 to 70°C

• No rapid changes in temperature and place where dew does not form

• Relative humidity of between 10 to 90% RH

• No presence of corrosive or flammable gases

• Place free of dust, salts and iron particles

• Place free of vibration and shock

• Place out of direct sunlight

• Place where it will not come into contact with water, oils or chemicals

• Place not affected by strong electro-magnetic waves

• Place not near to high-voltage, or high-power equipment

• For good heat dissipation, install the product only in the position written this manual or Instruction

Sheet so as not to block the ventilation holes.

• For good heat dissipation, keep the distance written this manual or Instruction sheet.

• Do not install the product immediately above significant heat sources, such as heaters, transformers,

or large-capacity resistors.

• Do not let the ambient temperature exceed an operating temperature range.

• Provide a forced-air fan cooling or air conditioning if the ambient temperature is near the upper range

of operating temperature range so that the ambient temperature never exceeds the upper range of

operating temperature range.

Installation and Storage Sites for FH-1000, FH-3000, FZ5-1100,

FZ5-600, FZ5-L Series

Installation and Storage Sites: FH-L series

Orientation of Product

Ambient Temperature
