5 - 33
5 Setup and Wiring
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
5-6 Insert SD Memory Card or USB memory
5
5-6-2 FH-L Series
Precautions for Correct Use
Handling of SD memory card
• When you touch a terminal part of SD memory card, antistatic is required by using a wrist
strap or others.
• Do not insert an SD memory card in the reverse orientation, at an angle, or in a twisting man-
ner.
Removing SD memory card
• Before removing a SD memory card, make sure that data is not being read or written to them.
• For an SD memory card, the SD BUSY LED of Sensor Controller flashes while data is being
read or written.
Make sure that the LED stops flashing before removing the card.
• When a message is displayed indicating that a task is in progress, do not turn OFF the
power.
Doing so causes the data in the memory to be corrupted, resulting in the product not operat-
ing properly upon the next start-up.
Do not insert or remove SD memory card during measurement, loading, and writing.
There is the possibility of measurement time or damage of data.
Additional Information
For external memory device, refer to the Using External Memory Devices in Vision System
FH/FZ5 Series User’s Manual (Cat. No. Z365).
Additional Information
For external memory device, refer to the Using External Memory Devices in Vision System
FH/FZ5 Series User’s Manual (Cat. No. Z365).
5-6-2 FH-L Series
5-6-3 FZ5 Series
