Omron fh series Hardware Manual

6 - 23
6 I/O Interface
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
6-1 Parallel Interface
6
6-1-5 PNP Input/Output for FZ5 Series
Parallel interface differs the appropriated Sensor Controller depending on NPN output and PNP output.
Encoder interface (open corrector type) is also included.
Encoder interface (open corrector type) is ENCTRIG_A0, ENCTRIG_B0, and ENCTRIG_Z0
Wire the pins to Encoder appropriately.
z
PNP I/O type
• Camera 2ch type: FZ5-1105/FZ5-605
• Camera 4ch type: FZ5-1105-10/FZ5-605-10
• Specifications differ by number of pins.
• Encoder interface (open corrector type) is ENCTRIG_A0 (B2pin), ENCTRIG_B0 (B3pin), and
ENCTRIG_Z0 (B4 pin). The frequency response of Encoder interface (open corrector type) is 0.95
KHz.
z
[Input]
Applicable signals:
RESET, DI0 to DI7, DSA0, DSA1
6-1-5 PNP Input/Output for FZ5 Series
Interface Specification
Item Specifications
Input voltage 12 to 24 VDC ±10%
ON current
*1
*1. ON current and ON voltage:
Those mean the current or voltage to turn ON from OFF. The ON voltage value is the potential difference
between COMIN and each input terminal.
5 mA min.
ON voltage
*1
8.8 V min.
OFF current
*2
*2. OFF current and OFF voltage:
Those mean the current or voltage to turn OFF from ON. The OFF voltage value is the potential difference
between COMIN and each input terminal.
0.5 mA max.
OFF voltage
*2
1.1 V max.
ON delay 5 ms max.
OFF delay 0.7 ms max.
