1 Confirm the Package
1 - 2
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
1-1 Sensor Controller
First, please check to see if the package has all the necessary Sensor Controller parts.
• Sensor Controller: 1
FH-1 or FH-3: 1
• Instruction Sheet (Japanese and English): 1
• Instruction Installation Manual for FH series: 1
• General Compliance Information and Instructions for EU: 1
• Power source: 1 (male)
FH-XCN: 1
• Ferrite core for camera cable: 2
• Sensor Controller: 1
FH-1-10 or FH-3-10: 1
• Instruction Sheet (Japanese and English): 1
• Instruction Installation Manual for FH series: 1
• General Compliance Information and Instructions for EU: 1
• Power source: 1 (male)
FH-XCN: 1
• Ferrite core for camera cable: 4
1-1-1 FH-1

/ FH-3

Series
1-1-2 FH-1

-10 / FH-3

-10 Series
