3 Configuration
3 - 8
Vision System FH/FZ5 series Hardware Setup Manual (Z366)
3-1-2 FH-L Series
Specification
Sensor Controller Series FH-L series
Type Lite Controller
Sensor Controller Model FH-L550 FH-L550-10
Controller Type BOX type
Parallel IO NPN/PNP (common)
Main Func-
tions
Operation
Mode
Standard Yes
Double Speed Multi-input Yes
Non-stop adjustment mode Yes
Multi-line random-trigger
mode
No
Parallel Processing NPN/PNP (common)
Number of Connectable Camera 2 4
Supported
Camera
FH-S series camera All of the FH-S series cameras are connectable
FZ-S series camera All of the FZ-S series cameras are connectable.
Camera I/F OMRON I/F
Possible Number of Captured Images Refer to About Number of Logging Images or About Max. Num-
ber of Loading Images during Multi-input in the Vision System
FH/FZ5 series User's Manual (Cat. No. Z365).
Possible Number of Logging Images to
Sensor Controller
Possible Number of Scenes 128
UI Opera-
tions
USB Mouse Yes (wired USB driver-less type)
Touch Panel Yes (RS-232C/USB connection: FH-MT12)
Setup Create the processing flow using Flow editing.
Language Japanese, English, Simplified Chinese, Traditional Chinese,
Korean, German, French, Spanish, Italian
External
Interface
Serial Communication RS-232C × 1
Ethernet
Communi-
cation
Protocol Non-procedure (TCP/UDP)
I/F 1000BASE-T × 1
EtherNet/IP Communication Ethernet port (transmission rate: 1 Gbps)
EtherCAT Communication No
Parallel I/O • High-speed input: 1
• Normal speed: 9
• High-speed output: 4
• Normal speed: 23
Encoder Interface None
Monitor Interface DVI-I output (Analog RGB & DVI-D single link) × 1
USB I/F USB2.0 host × 1: BUS Power: Port 5 V/0.5 A
USB3.0 × 1: BUS Power: Port 5 V/0.5 A
SD Card I/F SDHC × 1
Indicator
Lamps
Main POWER: Green
ERROR: Red
RUN: Green
ACCESS: Yellow
Ethernet NET RUN: Green
NET LINK ACT: Yellow
SD Card SD POWER: Green
SD BUSY: Yellow
EtherCAT None
